Egon 36 Angular encoder
Single-turn absolute single or redundant angular encoder with magnetic technology, emulating a traditional potentiometer thanks to the resulting analog output, featuring immunity to disturbances. It reads the shaft position within a range of 0°-360°, transforming it into the corresponding analog signal. It is used in major industrial sectors, from automation to robotics, from the medical field to the marine industry, and from entertainment to automotive.
Features
- Possibility of using long cables without causing instability.
- Maximum level of safety guaranteed by the double stage redundant scheme (redundant version).
- IP protection degree: Egon 36 is classified IP 65.
- Extreme temperature resistance: from -25°C to +85°C.
- Featuring wear-resistant technopolymer housing and stainless steel AISI 303 shaft.
Options
- Available with analog output: current 4...20mA, voltage 1...5 V, or voltage 2...10 V.
- Single or redundant version available.
- Featuring protection against input/output over-current and over-voltage and against reverse polarity.
- Available with con cable clamp or with connector.
- Available with clamping flange and adapter coupling (Ø 6-6, Ø 6-8, Ø 6-10).
Certifications
- CE marking.
GENERAL TECHNICAL SPECIFICATIONS
| Ambient temperature | Storage -25°C/+85°C |
|---|---|
| Operational -25°C/+85°C | |
| IP protection degree | IP 65 |
| Rated rotation speed | 800 rpm |
| Maximum rotation speed | 1500 rpm |
| Mechanical life | 30x106 revolutions |
| Shaft diameter | 6 mm |
| Connections | Male connector M8 - 4 PIN |
| Cable gland M8 with cable |
ELECTRICAL SPECIFICATIONS
| Power supply | 12...30 Vdc |
|---|---|
| Analog output | Current 4...20 mA |
| Voltage 1...5 V | |
| Voltage 2...10 V | |
| Consumption | 35 mA simple version |
| 55 mA redundant version | |
| Single-turn resolution | 12 bit (4096 points per revolution) |
| Protection against input/output over-voltage | Yes |
| Protection against input/output over-voltage | Yes |
| Accuracy | ± 0.5% |
| Linearity | ± 0.25% |
| Redundancy | 2 complementary outputs (analog) |
