Alpha Pendant control stations

Features

• Reduced installation and wiring time and costs: the switches feature terminals facing the cable clamp of the control station and screws on the opposite site to facilitate wiring.
• The pendant control panel has an angle of inclination giving the operator the best view of all the control elements and enabling a natural, comfortable working position.
• The emergency stop mushroom pushbutton complies with standard ISO 13850.
• Positive opening NC contacts for safety functions.
• Mechanical life of switches: 1 million operations.
• IP protection degree: Alpha is classified IP 65.
• Extreme temperature resistance: -25°C to+70°C.
• All materials and components used are wear resistant and guarantee protection of the unit against water and dust.

Options

• Pendant control panel available in configurations from 2 to 13 actuators arranged on a double row.
• Single or double switches with NO or NC contacts featuring one or two speeds.
• Wide range of actuators: pushbuttons, selector switches and key-selector switches in various operation configurations, pilot lights, latched mushrooms pushbuttons with rotation release or key-operated.
• Available with label (symbols and lettering) to be stuck next to the actuators.

Certifications

• CE marking.

GENERAL TECHNICAL SPECIFICATIONS

TECHNICAL SPECIFICATIONS OF THE SWITCHES
