Tango Position limit switches

Position limit switch equipped with rods
Catalog
Request form
Instructions
Certificates

Position limit switch designed for controlling the movement of overhead cranes, hoists, and complex industrial machines. The Tango limit switch is equipped with rods that move in maintained positions every 60°; it is also available with 2, 3, or 4 switches and rods of different lengths.

Shop 3D View Configurator

Features

  • Modern design and overall dimensions studied to facilitate installation and maintenance operations.
  • 4 fixing holes.
  • Rods with 4 maintained positions every 60°.
  • Mechanical life of switches: 1 million operations.
  • Operation frequency: 3600 operations / hour max.
  • IP protection degree: Tango is classified IP 65.
  • Extreme temperature resistance: -25°C to +70°C.
  • Enclosure and head in thermoplastic material (nylon reinforced with fiberglass) and internal components in technopolymers to guarantee long life-cycle and constant performance.
  • All materials and components used are wear resistant and guarantee protection of the unit against water and dust.

Options

  • Slow action switches with 1NC or 1NO contacts.
  • Available with 2, 3 or 4 switches and different rod lengths.

Certifications

  • CE marking.

GENERAL TECHNICAL SPECIFICATIONS

Ambient temperature Storage -40°C/+70°C
Operational -25°C/+70°C
IP protection degree IP 65
Operation frequency Class II
Operation frequency 3600 operations/hour max
Cable entry Cable gland M20

TECHNICAL SPECIFICATIONS OF THE SWITCHES

Utilisation category AC 15
Rated operational current 250 Vac
Rated operational voltage 3 A
Rated thermal current 10 A
Rated insulation voltage 500 Vac
Mechanical life 1x106 operations
Connections Screw-type terminals

Applications

Compenenti di comando e sicurezza per argani e paranchi
Winches - Hoists
Compenenti di comando e sicurezza per carroponti
Overhead travelling cranes - Gantry cranes
Automation - Assembly lines - Machine tools
