RCL Radio remote controls
Remote control with handheld transmitter, featuring an extremely compact and lightweight design. Thanks to its multiple customization options and programmable functions, this remote control is capable of meeting the needs of operators across a wide range of sectors.
Features
- Radio remote controls featuring an extremely compact and handy design, with an high degree of personalization.
- Easy and user-friendly coding featuring over 16 million codes for safety.
- Transmitters with green button to turn receiver on, red button to turn it off and fast flashing LEDs for low battery warning.
- Pushbuttons with tactile dome or rubber membrane with carbon contact.
- IP protection degree: RCL remote controls are classified IP 55 and IP 65 / IP 67.
- Extreme temperature resistance: from -20°C to +55°C.
Options
- Available in configurations from 2 to 20 buttons featuring up to 40 programmable functions (version with Shift option), ON and OFF button.
- Versions with 2,4 or 6 functions, featuring stainless steel faceplate with vandal proof security buttons, available on request to work in the harshest of environments.
- Hard wired remote controls (from 2 to 20 functions), with a curly cable attached, streatching out from 0.45 m to 4,5 (0,45 - 4,5 m) to connect directly to the receiver, available on request.
- Optional external antennas to be simply added to the SMA fitting to maintains full operating range of 60 / 300 metres in adverse conditions.
- Wide range of high quality solenoids to carry loads that are well in excess of the 15 amp relays.
- Air Actuator System designed for sectors which use hydraulic valves with levers for controlling the operative functions.
- Two styles of housing the transmitter when it's not in use: a basic version and one featuring a buzzer and light, used to warn that the transmitter is missing from its holder.
- Possibility to private label the transmitter with a personalized brand (only for large volumes) and to configure the right legends of the buttons.
- Magnets to enable the user to place the transmitter on metal surface and clear plastic IP67 or fabric / clear face covers with lanyard included available on request.
- Receivers featuring Master Output available, to give an extra indipendent control from the trasmitter and customizable by software for a wide variety of applications.
- Possibility to control multiple receivers from the same transmitter by software programme and to add switches to the side of teh receiver to cut off power and control the system.
- Customized harness wiring from own wiring diagram and protective potting / ruggedisation of the receiver PCB.
Certifications
- CE Marking.
- FCC Certification.
TECHNICAL SPECIFICATIONS OF THE TRANSMITTER UNIT
| Type | RCL M2 | RCL S | RCL I |
|---|---|---|---|
| Operational ambient temperature | -25°C/+55°C | ||
| IP protection degree | IP 65 / IP 67 | IP 55 | IP 65 / IP 67 |
| Pushbuttons configuration | 1 power on pushbutton + 1 power off pushbutton + 2 or 4 functions pushbuttons | 1 power on pushbutton + 1 power off pushbutton | 1 power on pushbutton + 1 power off pushbutton + 2 / 4 / 6 / 8 - 10 / 12 - 16 / 18 - 20 functions pushbuttons |
| - | 1 power on pushbutton + 1 power off pushbutton + 2 / 4 / 6 functions pushbuttons | Shift option: up to 40 functions | |
| - | - | Stainless option: 1 power on pushbutton + 1 power off pushbutton + 2 / 4 / 6 functions pushbuttons | |
| Type of pushbuttons | Rubber membrane with carbon contact | Tactile dome | |
| Quiescent current draw | 4 μA | 15 μA | |
| Operating current draw | 20 mA | 24 mA | |
| Protection against reverse polarity | Yes | ||
| Registration codes | > 16 million | ||
| Range | 45 m (from the receiver, when driving a momentary output, without signal drop out) 150 m optional | 60 m (from the receiver, when driving a momentary output, without signal drop out) 300 m optional | |
| Transmitted Power | 1 mW | ||
| Power supply | 2 x 1.5 V battery (AAA) | 1 x 9 V battery (PP9) | 4 x 1.5 V battery (AAA) |
TECHNICAL SPECIFICATIONS OF THE RECEIVER UNITS
| Type | Mini RX | Standard 15-amp FET’s | Deep 15-amp FET’s | Keypad |
|---|---|---|---|---|
| Operational ambient temperature | -40°C/+80°C | -40°C/+70°C | ||
| IP protection degree | IP 66 | |||
| Functions | 2 | 2 / 4 / 6 | 10 / 16 / 20 | 2 / 4 / 6 |
| Frequency | 433.050 ÷ 434.790 MHz | |||
| Modulation | 2-GFSK. Gaussian Frequency Shift Keying | |||
| Sensitivity | -113.7 dBm ÷ -81.3 dBm | |||
| Antenna impedance | 50 Ohm | |||
| Power supply | 12/24V DC (Nominal) | |||
| Power consumption | 0.372 W a 12 V e 0.408 W a 24 V | |||
| Antenna | Internal – ¼ wave wire --- SMA Connector fitted for extension | |||
| Standby current consumption | 31mA 12 V / 17 mA 24 V | |||
| Relays | 7.5A rated Mosfet (Positive Switching) | 10A rated Mosfet (Positive Switching) | ||
| Housing material | Clear PVC (Lid) – Black ABS (Base) | Clear PC/FR V0 and UV stabilised (Lid) – Black PC V0 and UV stabilised (Base) | ||
